Panel Profiles

R Panel

The R- and PBR-panels are excellent light-duty roofing and siding panels, allowing for maximum spans in roof and wall application due to 12″ rib spacing.

R-Panel Features:          Color Chart          Download Spec Sheet

  • Available in 36″ coverage with 1 1/4″ high ribs.
  • Ideal for self-storage, commercial/industrial wall application, equipment screens, agricultural and residential construction.
  • Purlin bearing leg option for roofing application.
  • Reversed run profiles for wall applications make an attractive shadow panel.
  • R-panel is available in a wide variety of colors and finishes.
  • Matching Galvalume® pre-painted finishes are available for flashings and flat stock.
  • Color match fasteners are self-sealing and available for wood and steel applications.
  • Panel lengths up to 65 feet are available to minimize laps at no extra charge.
  • Galvalume® warranty 25 years and pre-painted material warranty 30 years.

U Panel

The U- and PBU-panels are excellent light-duty roofing, siding and partition panels, allowing for fewer vack laps and easier installation due to 6″ rib spacing.

U-Panel Features:          Color Chart          Download Spec Sheet

  • Available in 36″ coverage with 3/4″ high ribs.
  • Ideal for self-storage, commercial/industrial wall applications, equipment screens, agricultural and residential construction.
  • Purlin bearing leg option for roofing application.
  • U-panel is available in a wide variety of colors and finishes.
  • Matching Galvalume® pre-painted finishes are available for flashings and flat stock.
  • Color match fasteners are self-sealing and available for wood and steel applications.
  • Panel lengths up to 65 feet are available to minimize laps at no extra charge.
  • Galvalume® warranty 25 years and pre-painted material warranty 30 years.

5V Panel

Download Spec Sheet

The 5V-panels are a high quality steel that provide a classic look.  It’s versatility makes for a great performance in nearly any style of roofing.  The panels double overlap helps assure a water-tight seal.  The panels should be installed over plywood and 30lb. felt.  **This panel is available in Galvalume® only.

5-V Panel Features:

  • available in 24″ coverage with 1/2″ ribs on 12 inch centers.
  • Ideal for industrial/commercial, residential and agricultural applications.
  • A full line of standard and custom trim items are available.
  • Minimum roof slop 3:12.
  • Galvalume® warranty 25 years.
  • Panels are UL 2218 Class 4 Hail Impact Resistant and Texas Windstorm rated.
